Grondvochtigheid sensor capacitief analoog 3-polig v1.2 met JST-XH 2.54mm pitch connector

Oorspronkelijke prijs was: € 2,52.Huidige prijs is: € 1,82. incl. BTW

Availability: 5 op voorraad Artikelnummer: OP-2026-GVSC12 Categorie: Tags: , , , , , , ,
Vergelijken

Beschrijving

Deze grondvochtigheid sensor is minder gevoelig voor corrosie door middel van capacitieve metingen.

Wordt geleverd met kabeltje  JST-XH 2.54mm pitch female naar 3P dupont 2.54mm pitch female

Features:
Use for garden plants, moisture detection, intelligent agriculture.
Includes an onboard voltage regulator that gives it an operating range of 3.3~5.5V.
Measure moisture levels based on a capacity sensor.
Analog output, insert it into the soil and feedback with the real time soil voisture data.
Supports 3-pin Gravity Sensor interface. Compatible with DFRobot 3-pin “Gravity” interface, which can be directly connected to the Gravity I/O expansion holds.

Specifications:
Operating voltage: 3.3 ~ 5.5 VDC.
Output Voltage: 0~3.0 VDC
Interface: XH2.54 3P
Dimensions: 98mm x 23mm / 3.86″ x 0.91″

PCB thinckness = 1.2mm

Extra informatie

Gewicht 12 g
Afmetingen 10 × 2 × 1 mm
