HDD PATA/100 2.5″ 30GB / Hitachi Travelstar (IC25N030ATMR04)

Beschrijving

HDD PATA/100 2.5" 30GB / Hitachi Travelstar (IC25N030ATMR04)

GENERAL

• Capacity
  30 GB
• Interface
  ATA-100
• Buffer Size
  2 MB
• Weight
  3.4 oz
• Manufacturer
  Hitachi

POWER DEVICE

• Type
  none

MISCELLANEOUS

• Microsoft Certifications
  Works with Windows Vista
• Works with Windows Vista
  Software and devices that carry the Works with Windows Vista logo have been tested for baseline compatibility with PC's running.

INTERFACE PROVIDED

• Qty
  1
• Connector Type
  44 pin IDC
• Storage Interface
  ATA-100
• Interface
  ATA-100

EXPANSION & CONNECTIVITY

• Interfaces
  1 x ATA-100 – 44 pin IDC
• Compatible Bays
  1 x internal – 2.5" x 1/8H

PERFORMANCE

• Internal Data Rate
  43.8 MBps
• Seek Time
  12 ms (average) / 23 ms (max)
• Drive Transfer Rate
  100 MBps (external)
• Average Latency
  7.1 ms
• Spindle Speed
  4200 rpm
• Track-to-Track Seek Time
  2.5 ms

HARD DRIVE

• Form Factor
  2.5" x 1/8H
• Interface Type
  ATA-100
• Spindle Speed
  4200 rpm
• Features
  antiferromagnetically-coupled (AFC) media, Fluid Dynamic Bearing (FDB) motor, Partial Response Maximum Likelihood (PRML), Giant magnetoresistive (GMR) head technology, Enhanced Adaptive Battery Life Extender 3.0, TrueTrack servo technology
• Hard Drive Type
  internal hard drive
• Form Factor (Short)
  2.5"
• Form Factor (metric)
  6.4 cm x 1/8H
• Form Factor (Short) (metric)
  6.4 cm
• Storage Interface
  ATA-100
• Interface
  ATA-100
• Average Seek Time
  12 ms
• Max Seek Time
  23 ms
• Track-to-Track Seek Time
  2.5 ms
• Average Latency
  7.1 ms
• Data Transfer Rate
  100 MBps
• Internal Data Rate
  43.8 MBps
• Buffer Size
  2 MB
• Non-Recoverable Errors
  1 per 10^13
• Start / Stop Cycles
  300,000

STORAGE CONTROLLER (2ND)

• Type
  none

ENVIRONMENTAL PARAMETERS

• Vibration Tolerance
  0.67 g @ 5-500 Hz (operating) / 3.01 g @ 5-500 Hz (non-operating)
• Max Altitude Operating
  9840 ft
• Min Operating Temperature
  41 °F
• Max Operating Temperature
  131 °F
• Humidity Range Operating
  8 – 90%
• Sound Emission
  23 dB
• Sound Emission
  23 dB
• Shock Tolerance
  200 g @ 2ms (operating) / 800 g @ 1ms (non-operating)

STORAGE HARD DRIVE

• Compliant Standards
  S.M.A.R.T.

HEADER

• Brand
  HGST
• Product Line
  HGST Travelstar 80GN
• Model
  IC25N030ATMR04
• Packaged Quantity
  1
• Compatibility
  PC

BAY REQUIRED

• Type
  internal
• Form Factor
  2.5" x 1/8H
• Form Factor (metric)
  6.4 cm x 1/8H
• Total Qty
  1

Extra informatie

Merk

Hitachi
