Beschrijving
Dit is een 2e KANS artikel/product, en is getest op werking/functionaliteit! — GARANTIE 14 dagen na aankoop — |
| General information | |
| Type | CPU / Microprocessor |
| Market segment | Desktop |
| Family | AMD FX-Series |
| Model number ? | FX-6100 |
| CPU part numbers | FD6100WMW6KGU is an OEM/tray microprocessorFD6100WMGUSBX is a boxed microprocessor with fan and heatsink |
| Frequency ? | 3.3 GHz / 3300 MHz |
| Maximum turbo frequency | 3.9 GHz / 3900 MHz |
| Bus speed ? | One 2600 MHz 16-bit HyperTransport link |
| Package | 940-pin organic micro Pin Grid Array (UOC940) Pb-free |
| Socket | Socket AM3+ |
| Size | 1.57″ x 1.57″ / 4cm x 4cm |
| Weight | 1.4oz / 38.6g (CPU) 1lb 4.9oz / 593.4g (box) |
| Fan/heatsink | CKM-7X52A-A1-GP |
| Introduction date | October 12, 2011 |
| Price at introduction | $165 |
| Architecture / Microarchitecture | |
| Instruction set | x86 |
| Microarchitecture | Bulldozer |
| Platform | Scorpius |
| Processor codename | Zambezi |
| Core stepping ? | OR-B2 |
| CPUID | 600F12 |
| Manufacturing process | 0.032 micron Hi-K Metal Gate process with silicon-on-insulator (SOI) technology |
| Die | 316mm2 |
| Data width | 64 bit |
| The number of CPU cores | 6 |
| The number of threads | 6 |
| Floating Point Unit | Integrated (shared between each pair of cores) |
| Level 1 cache size ? | 3 x 64 KB instruction caches 6 x 16 KB data caches |
| Level 2 cache size ? | 3 x 2 MB |
| Level 3 cache size | 8 MB |
| Cache latency | 3 (L1 cache) |
| Multiprocessing | Uniprocessor |
| Extensions & Technologies | MMX instructionsExtensions to MMXSSE / Streaming SIMD ExtensionsSSE2 / Streaming SIMD Extensions 2SSE3 / Streaming SIMD Extensions 3SSSE3 / Supplemental Streaming SIMD Extensions 3SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ? SSE4a ? AES / Advanced Encryption Standard instructionsAVX / Advanced Vector ExtensionsFMA4 / 4-operand Fused Multiply-Add instructionsXOP / eXtended Operations instructionsAMD64 / AMD 64-bit technology ? AMD-V / AMD Virtualization technologyTurbo Core 2.0 technology |
| Security Features | EVP / Enhanced Virus Protection ? |
| Low power features | PowerNow! |
| Integrated Graphics Processing Unit | |
| None | |
| Integrated peripherals / components | |
| Memory controller | The number of controllers: 1 Memory channels (per controller): 2 Memory channels (total): 2 Supported memory: DDR3-1866 |
| Other peripherals | HyperTransport 3.1 technology |
| Electrical / Thermal parameters | |
| V core ? | 0.925V – 1.4125V |
| Maximum operating temperature ? | 70°C |
| Thermal Design Power ? | 95 Watt |
Extra informatie
| Gewicht | 100 g |
|---|---|
| Afmetingen | 4 × 4 × 0,7 mm |
| Processor familie | |
| Thermal Design Power (Watt) | |
| Processor kern (naam) | |
| Aantal kernen | |
| Instructieset | |
| Frequentie processor (GHz) | |
| Bus snelheid (MHz) | |
| L1 cache size (KB) | |
| Bouwjaar | |
| L2 cache size (MB) | |
| Package type | |
| Socket type | |
| Lithografie (nm) |
Merk
AMD
