RJ connector 8P8C female shielded verticaal met leds RJ45 PCB
€ 0,90 incl. BTW
Availability: 144 op voorraad
Artikelnummer: CON-3019-8P8LV
Categorieën: Computer Netwerk componenten, Connector (PCB), RJ connector (Telefoon / Netwerk)
Tags: 8P8C, connector, female, leds, PCB, RJ, RJ45, shielded, verticaal
- Beschrijving
- Extra informatie
- Downloads
- Q & A
Beschrijving
Nominale Spanning: 125 VAC RMS;
Nominale Stroom: 1.5A;
Contact Weerstand: 50 mq Max;
Isolatie Weerstand: 500M Ohm Min @ 500VDC;
Diëlektrische Weerstaan Spanning: 1000 v AC RMS 50 hz 1 min;
Behuizing Materiaal: Glas Gevuld Polyester (UL94V-0);
Contact Materiaal: Fosforbrons & phi; 0.46mm (C5100);
Plating: Gold Plating Over Nikkel;
Schild: Koper Legering 0.20mm Dikte plating NI;
PCB Retentie Pre-soldeer: 1 LB Min;
Enviromental:-° c ~ ° c;
Mates met modulaire stekker voldoet aan FCC Part68, Subdeel F;
Extra informatie
Gewicht | 5 g |
---|---|
Afmetingen | 2 × 2 × 1,5 mm |
