Stroommeter sensor AC 5A verhouding 1000-1 5mA analoog ZMCT103C
€ 0,88 incl. BTW
Availability: 80 op voorraad
Artikelnummer: SEN-2101-T103C
Categorie: Stroom / Spanning sensor
Tags: 5A, 5mA, AC, Analoog, Stroommeter, verhouding 1000-1, ZMCT103C
- Beschrijving
- Extra informatie
- Q & A
Beschrijving
Feature:
Product model: ZMCT103C
Rated Input Current: 5A
Rated output current: 5mA
Ratio: 1000:1
Phase (when the rated input) : <= 15(100 ohm)
The linear range: 0-15A(100 ohm)
Linearity :0.2%
Isolation voltage: 4500V
Uses: For Current and power measurement
Sealing material: epoxy resin
Installation method: printed board installation
Working temperature: -40 to +85 degrees
Shell material: ABS
Extra informatie
Gewicht | 8 g |
---|---|
Afmetingen | 3 × 3 × 2 mm |
