Webcam UVC Trust Primo zwart 640×480 1.5M USB-A + 3.5mm Jack 17405 (2e kans)

Beschrijving

Dit is een 2e KANS (vintage) artikel/product, en is mogelijk getest op werking/functionaliteit! het product kan eventuele gebuikersporen bevatten.

— GARANTIE 14 dagen na aankoop —

Windows:

UVC (USB Video Class) apparaat, werkt op Windows 7/8/10/11

Linux:
Werkt!

---

lsusb

Bus 001 Device 003: ID 145f:0187 Trust Trust Webcam

dmesg

usb 1-1: new high-speed USB device number 3 using ehci-platform
usb 1-1: New USB device found, idVendor=145f, idProduct=0187, bcdDevice= 1.00
usb 1-1: New USB device strings: Mfr=2, Product=1, SerialNumber=0
usb 1-1: Product: Trust Webcam
usb 1-1: Manufacturer: Trust Webcam
usb 1-1: Found UVC 1.00 device Trust Webcam (145f:0187)
input: Trust Webcam: Trust Webcam as /devices/platform/soc/5200000.usb/usb1/1-1/1-1:1.0/input/input2

---

v4l2-ctl –device=/dev/video1 –all

Driver Info:
        Driver name      : uvcvideo
        Card type        : Trust Webcam: Trust Webcam
        Bus info         : usb-5200000.usb-1
        Driver version   : 6.1.31
        Capabilities     : 0x84a00001
                Video Capture
                Metadata Capture
                Streaming
                Extended Pix Format
                Device Capabilities
        Device Caps      : 0x04200001
                Video Capture
                Streaming
                Extended Pix Format
Media Driver Info:
        Driver name      : uvcvideo
        Model            : Trust Webcam: Trust Webcam
        Serial           :
        Bus info         : usb-5200000.usb-1
        Media version    : 6.1.31
        Hardware revision: 0x00000100 (256)
        Driver version   : 6.1.31
Interface Info:
        ID               : 0x03000002
        Type             : V4L Video
Entity Info:
        ID               : 0x00000001 (1)
        Name             : Trust Webcam: Trust Webcam
        Function         : V4L2 I/O
        Flags            : default
        Pad 0x01000007   : 0: Sink
          Link 0x02000013: from remote pad 0x100000a of entity 'Extension 5' (Video Pixel Formatter): Data, Enabled, Immutable
Priority: 2
Video input : 0 (Input 1: ok)
Format Video Capture:
        Width/Height      : 640/480
        Pixel Format      : 'YUYV' (YUYV 4:2:2)
        Field             : None
        Bytes per Line    : 1280
        Size Image        : 614400
        Colorspace        : sRGB
        Transfer Function : Rec. 709
        YCbCr/HSV Encoding: ITU-R 601
        Quantization      : Default (maps to Limited Range)
        Flags             :
Crop Capability Video Capture:
        Bounds      : Left 0, Top 0, Width 640, Height 480
        Default     : Left 0, Top 0, Width 640, Height 480
        Pixel Aspect: 1/1
Selection Video Capture: crop_default, Left 0, Top 0, Width 640, Height 480, Flags:
Selection Video Capture: crop_bounds, Left 0, Top 0, Width 640, Height 480, Flags:
Streaming Parameters Video Capture:
        Capabilities     : timeperframe
        Frames per second: 25.000 (25/1)
        Read buffers     : 0

User Controls

                     brightness 0x00980900 (int)    : min=-64 max=64 step=1 default=2 value=2
                       contrast 0x00980901 (int)    : min=0 max=64 step=1 default=36 value=36
                     saturation 0x00980902 (int)    : min=1 max=128 step=1 default=70 value=70
                            hue 0x00980903 (int)    : min=-40 max=40 step=1 default=0 value=0
        white_balance_automatic 0x0098090c (bool)   : default=1 value=1
                          gamma 0x00980910 (int)    : min=72 max=500 step=1 default=77 value=77
                           gain 0x00980913 (int)    : min=0 max=100 step=1 default=0 value=0
           power_line_frequency 0x00980918 (menu)   : min=0 max=2 default=1 value=1 (50 Hz)
                                0: Disabled
                                1: 50 Hz
                                2: 60 Hz
      white_balance_temperature 0x0098091a (int)    : min=2800 max=6500 step=1 default=6500 value=6500 flags=inactive
                      sharpness 0x0098091b (int)    : min=0 max=7 step=1 default=3 value=3
         backlight_compensation 0x0098091c (int)    : min=0 max=2 step=1 default=1 value=1

Camera Controls

                  auto_exposure 0x009a0901 (menu)   : min=0 max=3 default=3 value=3 (Aperture Priority Mode)
                                1: Manual Mode
                                3: Aperture Priority Mode
         exposure_time_absolute 0x009a0902 (int)    : min=1 max=5000 step=1 default=625 value=625 flags=inactive
     exposure_dynamic_framerate 0x009a0903 (bool)   : default=0 value=1
