CO2 Koolstofdioxide sensor 0-5000 ppm NDIR MH-Z19B met JST-micro 7P kabel

 28,81 incl. BTW

Availability: 6 op voorraad Artikelnummer: SEN-2015-MHZ1 Categorie: Tags: , , , , ,
Vergelijken

Beschrijving

Ter info:

– de aansluiting van de kabel kan ook “afgebroken” worden, zodat pin headers gesoldeerd kunnen worden.

Product Description

MH-Z19B carbon dioxide gas sensor (hereinafter referred to as the sensor) is a general-purpose smart small-scale sensor that uses non-dispersive infrared (NDIR) principle to detect the presence of CO2 in the air, with good selectivity and anaerobic  Gas dependence, long life and other characteristics; built-in temperature compensation; at the same time with serial output, analog output and PWM output, easy to use. The sensor is a high-performance sensor that combines mature infrared absorption gas detection technology with precise optical path design and sophisticated circuit design.

Product Parameters

1. Product model number: MH-Z19B

2. Gas Detection: Carbon Dioxide

3. Supply voltage: 4.5~5.5V DC

4. Average current: <20mA (@5V power supply)

5. Peak current: 150 mA (@5V supply)

6. Interface level: 3.3V (5V compatible)

7. Measurement range: 0~10000ppm can be selected within the range

8. Output signal: Serial (UART) (TTL level 3.3V)

                        PWM

                        Analog output (DAC) (default 0.4~2V) (0~3V range configurable)

9. Warm-up time: 3min

10. Response time: T90<120s

11. Working temperature: 0~50°C

12. Operating Humidity: 0 to 95% RH (non-condensing)

13. Weight: 5g

14. Life: >5 years

Sensor Characteristics

1. Gas chamber with gold plating, waterproof and corrosion resistant

2. High sensitivity, low power consumption

3. Excellent stability

4. Temperature compensation, excellent linear output

5. Provides serial (UART), analog (DAC), PWM waveform output methods

6. long lasting

7. Water vapor interference, not poisoning

Application

HVAC refrigeration equipment

Air quality monitoring equipment

Fresh air system

Air purification equipment

Smart home

SCHOOL

Extra informatie

Gewicht 200 g
Afmetingen 2 × 3 × 1 mm
